What is the use of a relay in an automation panel?

The primary role of a relay in an automation panel is to provide protection against high value of current. It also provides switching functions as it acts like a switch to cut-off supply to the secondary side.

What is the difference between HVX and PIX VCB?

HVX VCB is kind of medium voltage circuit breaker with a range from 12KV-24KV. During installation, operation, and maintenance, the PIX range is an interior switchgear assembly that ensures maximum user safety, simplicity, and reliability. It includes a range of novel technologies and covers all electrical distribution needs up to 24 kV. A PIX circuit breaker is a specific type of medium voltage air insulated circuit breaker. During installation, operation, and maintenance, the PIX range is an interior switchgear assembly that ensures maximum user safety, simplicity, and reliability. It satisfies all electrical distribution requirements up to 24 kV and has several novel features.

Explain the meaning of 'electrical balance of plant'?

Electrical balance of plant means a system that is used to regulate, monitor, and provide protection to the components of power plant using low, medium, and high voltage electrical devices. Some of the system includes power transformers, auxiliary transformers, switchgears, electrical busbars, etc.

What is the use of high-voltage wire?

High voltage wires are basically considered as those wires which is rated over 1000 volts. These wires are generally used for the purpose of electrical power transmission. The high voltage wires are designed in such a way that it prevents loss of power while transmission process.

How can we convert a high voltage power to a low voltage power?

A basic step-down transformer can be used to convert high-voltage electric power into low-voltage electricity. As the net power on both sides of the transformer must remain constant, what happens to current throughout this transformation is that it increases correspondingly in magnitude. (V*I is the same as the constant)

HV Panels

RMU Panel :

HV Panel the RMU cabinet, also known as a medium voltage cabinet, is a piece of integrated electrical equipment that connects, measures, and integrates fixed type breakers with transformer protection.

RMU cabinets are compact, extremely dependable, safe, simple to maintain, replace, and extend. The RMU is available in a variety of voltages that are suited for both indoor and outdoor installations, depending on your needs.

RMU cabinets are an innovative solution that easily solves many powers distribution challenges. RMU is an all-in-one solution because it is a secure substation, easy to install and free to maintain, and helps utilities improve network reliability and uptime and reduce operating costs.

It includes Load break switch, circuit breaker, fault passage indicators, Power supply unit, Potential Transformers, Current Transformers and HRC fuses, Solid-insulated busbars.

We are a supplier of fully assembled, enclosed Ring Main Units for MV/HV power distribution with a wide voltage range.

The voltage range may be considered as between 7200v – 36000v. We have experience in providing export quality RMU in pacific region. It comes in two different varieties indoor and outdoor type. We also provide associated cables, termination kits along with RMU for your project.

Advantages of using RING MAIN UNIT are as follows:

HV Panels VCB:

VCB panel is also used for protection in secondary side of the electrical system. It is installed in between feeder and transformer to provide protection to your transformer. The only thing is that it has only one incomer and one outgoing as compared to RMU.

Our High Voltage panels are highly appreciated by our clients due to its reliability and high efficiency, easy installation, and longer life along with low maintenance features

We offer these VCB Panels with different specifications and varieties, this provides more protection for any Electricity system in Medium as well as High Voltage Circuits.

It also comes in indoor and outdoor type with maximum voltage up to 36000v.

Benefits of VCB Panel:
